AR3 200 | ||
---|---|---|
Length | 2,280mm | |
Width | 1,055mm | |
Height | 1,600mm | |
Wheel Base | 1,751mm | |
Dry Weight | 231kg | |
Engine | PeugeotEngine Water-cooled 4 cycles/OHC 4-valves Liquid Engine | |
Bore x Stroke | 64mm x 58.8mm | |
Displacement | 190cc | |
Fuel system | Injection | |
Valve | OHC | |
Compression ratio | 12.0 : 1 | |
Max Power | 14kw / 8,500rpm | |
Max Torque | 17Nm / 6,900rpm | |
Starter system | Self-start | |
Fuel Capacity | 14L | |
Trasmissione | CVT | |
Suspension (FR) | telescopic hydraulic front forks 41mm | |
Suspension (RR) | Double Swing | |
Tyre (FR) | 120/70―14” | |
Tyre (RR) | 120/70―12” tubeless x2 | |
Brakes (FR) | Disk Brake 240mm | |
Brakes (RR) | Disk Brake 210mm x2 | |
Body Color | White, Graphite, Wine Red |
