AD1 means a great STABILITY and EXCELLENT road holding in all weather conditions, SECURITY on all road surfaces. AD1 is equipped with the patented MODULAR PROTECTION SYSTEM.

AD1 125/200cc
ENGINE TRANSMISSION
ENGINE single cylinder four-cycle
DISPLACEMENT 190 cc
BORE X STROKE 64 x 58,9 mm
MAX POWER 14kw @ 8500 rpm
MAX TORQUE 17 Nm @ 6700 rpm
GASOLINE unleaded petrol
LUBRICATION dry carter
ENGINE START electric start
COOLING liquid-cooled
GEAR CVT with automatic clutch
WHEELS
TYRES front 130/60 x 13″, rear 130/70 x13″ tubeless
RIMS 5 spokes aluminium rims, front 3.00 x 13″, rear 3.50 x 13″
FRONT BRAKE double 220 mm disc brake
REAR BRAKE 210 mm disc brake
FRAME
FRAME high-resistance steel pipe
FRONT SUSPENSIONS single two-ways shock absorber
REAR SUSPENSIONS engine behaving structural, double rear two-ways shock absorbers preload adjustable on 5 positions
SIZES
LENGTH 2061 mm
WIDTH 670 mm
HEIGHT 1680 mm
SEAT HEIGHT 700 mm
WHEEL BASE 1480 mm
DRY WEIGHT 182 kg
GASOLINE TANK 10,2 litres (2,0 litres reserve)
HOMOLOGATION
HOMOLOGATION Euro 3
ACCESSORIES Side deflectors
Roof deflectors
Thermo scud
Luggage’s strap
Rear spoiler
Roll-lock system
